2.2 HDI Euro 5 200 BHP Bosch EDC17CP42 Peugeot 508

Stage 1 Remap Peugeot 508 2.2 HDI(235 BHP | 490 Nm)

Our stage 1 remap offers a very advanced tuning solution for this complex tuning protected ECU (Bosch EDC17CP42) and unlocks every available Nm of torque whilst staying completely safe and giving maximum reliability for your engine.

Peak power will increase to 235 BHP with an exciting torque figure of 490Nm. With the Stage 1 remap installed you’ll notice a big difference in power delivery, torque will be constant and it will keep on giving. You’ll be able to easily pull all the way through the rev range. We’re sure this remap will put a big smile on your face.

You can program the ECU yourself using our online remapping service when you order the MyGenius OBD programming tool from our webshop.

If you prefer to send the ECU to us for the programming work, you can use our postal remap service.

Price:

• Program yourself with the MyGenius OBD tool, includes a Stage 1 Remap for just £290!
• Already have a programming tool? Use our Online remap service for just £150
• Send us your ECU – Use our Postal Remap Service £200

Programming Methods – OBD2 or bench programming

Only genuine tuning tools can program the EDC17CP42 over OBD, any clone tools from ebay will require the ECU to be removed. The best tool to use is DimSport MyGenius, this is available on our webshop.

Programming via OBD EDC17CP42

• Obtain a suitable programming tool. We recommend Dimsport MyGenius if you want to program over OBD.
• Install the tool to a reliable laptop.
• Connect to the OBD port of your car, make sure you have backup chargers to the vehicle battery and the laptop battery.
• ID the ECU and then take a read of the ECUs flash memory.
• Email the software to remap@hdi-tuning.co.uk along with a description of the remap you require.
• Send payment through our webshop.
• We will modify the software and send back to you. This normally takes less than 2 to 3 hours during working days.
• Using the same tool, ID then write to the ECU. This will overwrite the ECUs flash memory, it’s important not to interrupt the process. If you encounter any problems we can fix the ECU for you so there’s absolutely nothing to worry about.
• Let your engine warm up and then take the car for a spin, enjoy the extra power!

Programming via Bench service mode PCM Flash

This is our preferred way to program. The ECU must be removed, but there is no need to open the ECU and risk damage. A full backup can be made of both the EEPROM and the internal flash memories, also the external flash can be read on models where this is present.

• Order a tool such as KTM bench or PCM Flash AMT flash, any tool which supports bench service mode.
• Remove ECU from the vehicle.
• Connect specified wires to ECU plug connector.
• ID the ECU.
• Read the ECU memories.
• Email software to HDI Tuning.
• Wait for us to prepare your remap and return it back to you.
• Program the remap to the ECU using the same method taken to read the ECU.
• Refit the ECU, check engine starts.
• Let your engine warm up and then take the car for a spin, enjoy the extra power!

Programming via KTAG or MPPS Tricore

• Order a suitable tool such as Kess KTAG or MPPS Tricore
• Install the tool to a reliable laptop.
• The ECU must be removed from the vehicle, and then the lid can be carefully pried open and removed. The best way to do this is with 1 small flat head screw driver, 1 medium, and one large. A heat gun will help soften the sealant. Always start at the end furthest from the flat bonded section of the lid. If you attempt to pry open this end you will damage the ECU. A video guide is available on youtube.
• Connect necessary pins to ECU connector plug.
• Connect boot pin to correct location. The processor is a TC1793.
• ID the ECU.
• Take a read of all memories present.
• Email the software to remap@hdi-tuning.co.uk along with a description of the remap you require.
• Send payment through our webshop.
• We will modify the software and send back to you. This normally takes less than 2 to 3 hours during work days.
• Using the same tool, ID then write to the ECU. This will overwrite the ECUs memory, it’s important not to interrupt the process. If you encounter any problems we can fix the ECU for you so there’s absolutely nothing to worry about, if you made a backup of all memories you’re extra safe in the event that something were to go wrong.
• Straighten the lid on the ECU and seal with a little silicone.
• Refit the ECU and start the engine.
• Let your engine warm up and then take the car for a spin, enjoy the extra power!
